chapter 5000
page 3
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
BATTERY AND BATTERY CHARGER
General indications for battery maintenance
Every 50 working hours - measure electrolyte density.
Approximate density data
For a temperature of 15° C
- a density of 1.12 to 1.13+
kg/dm
3
indicates that the battery is flat;
- a density of 1.25 to 1.26 kg/dm
3
indicates that the battery is charged (battery capacity increased: 1.29 to 1.30
kg/dm
3
).
BATTERY CHARGING WARNINGS
Before charging the battery, verify that the room is well aerated. Open the battery compartment door.
Make sure that all electrical connections (electrical cable terminals, battery terminals, plugs-sockets, etc.) are well
attached and in good condition.
- Do not open either remove battery filling caps.
- Never top up before and while charging the battery.
- Do not smoke, do not stay close to naked flames and do not cause sparks next to batteries
- Do not use the battery while it is being charged
- Do not lean metal tools on the battery while under charge
- Never repair the battery while under charge
- Check that during the charging phase, the electrolyte temperature is kept below 50°C.
Warning
The battery normal working range is from 100% to 20% of the capacity. For the battery protection,
don’t let the residual capacity to drop down under 20% of the charge. Under this limit you can have
possible battery damages and, above all, logic units malfunctions and stops that could invalidate the
truck safe use.
BATTERY WEIGHTS AND CAPACITY
BATTERY
WEIGHT
775 kg
775 kg
920 kg
920 kg
1090 kg
1090 kg
1090 kg
775 kg
775 kg
920 kg
920 kg
1090 kg
1090 kg
1090 kg
TRUCK WHEELS
t.
1.2 3
1.5 3
1.6 3
1.8 3
2.0 3
1.6L 3
1.8L 3
1.2 4
1.5 4
1.6 4
1.8 4
2.0 4
1.6L 4
1.8L 4
WEIGHT WITH
STANDARD BATTERY
2960 kg
3190 kg
3230 kg
3375 kg
3565 kg
3335 kg
3440 kg
2950 kg
3140 kg
3180 kg
3320 kg
3520 kg
3300 kg
3380 kg
BATTERY
CAPACITY
420-500 Ah
420-500 Ah
525-625 Ah
525-625 Ah
630-750 Ah
630-750 Ah
630-750 Ah
420-500 Ah
420-500 Ah
525-625 Ah
525-625 Ah
630-750 Ah
630-750 Ah
630-750 Ah
