Cisco 7600 Series Module Guide

16-6
Cisco 7600 Series Routers Module Guide
OL-9392-04
Chapter 16 Adaptive Security Appliance Services Module
Restrictions and Configuration
The number of ASA SMs supported on the chassis for centralized and distributed forwarding is as
follows:
• Centralized Forwarding supports three ASA SM cards per chassis. Central forwarding has an ingress
and an egress supervisor EARL lookup.
• Distributed Forwarding supports four ASA SM cards per chassis. In distributed forwarding, ingress
lookup is done by the line-card, and egress lookup is done by the supervisor EARL.
Restrictions and Configuration
Restrictions
The following restrictions apply to ASA SM:
• ASA SM is only supported on the 7606-S and 7609-S chassis. Support for 7613-S and lead free
version of 7606-S will become available later.
• ASA SM is not supported on Cisco 7603 and Cisco 7604 routers.
ASA Configuration
ASA SM uses one of the following multi-card configurations to scale bandwidth:
• VLAN-based approach: This approach uses multiple ASA SMs per chassis. Each ASA SM is
assigned a distinct set of VLANs. Traffic is assigned to a specific ASA SM based on its incoming
or outgoing VLAN tag.
• Policy-based routing approach: This approach is similar to the VLAN-based approach except that
the supervisor uses a policy based routing (PBR) scheme based on the source of the traffic,
application types, or destination to route packets across multiple ASA SM cards.
Note For information on all ASA SM configurations, see Cisco ASA Services Module CLI Configuration
Guide available at:
http://www.cisco.com/en/US/docs/security/asa/asa84/configuration85/guide/asa_cfg_cli_85.html
Troubleshooting
Command Execution Location
Debug firewall RP of Supervisor
Debug trifecta SP of Supervisor
