Cisco Aironet 340 Series User Manual

F-4
Cisco Aironet Wireless LAN Client Adapters Installation and Configuration Guide for Windows CE
OL-1375-03
Appendix F Performing a Site Survey
Using Passive Mode
Using Passive Mode
Follow the steps below to activate the site survey passive mode and obtain current information about RF
network traffic.
Step 1 From the Profiles screen, tap the Survey tab. The Site Survey - Passive screen appears (see Figure F-2),
provided a client adapter is installed in the Windows CE device and is running.
Figure F-2 shows the Site Survey - Passive Mode screen with the signal strength values displayed as
percentages, and Figure F-3 shows the same screen with the signal strength values displayed in dBm.
Figure F-2 Site Survey - Passive Screen (with Signal Strength as a Percentage)
Figure F-3 Site Survey - Passive Screen (with Signal Strength in dBm)
