Cisco Catalyst 3650 Series Hardware Installation Guide

1-31
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 1 Product Overview
Rear Panel
Figure 1-15 is a representative illustration for the following switch models:
• WS-C3650-8X24UQ-L/S/E
• WS-C3650-8X24PD-L/S/E
• WS-C3650-12X48UZ-L/S/E
• WS-C3650-12X48UR-L/S/E
• WS-C3650-12X48UQ-L/S/E
• WS-C3650-12X48FD-L/S/E
RJ-45 Console Port LED
The RJ-45 Console Port LED indicates whether the RJ-45 console is enabled or disabled.
StackWise Ports
StackWise ports are used to connect switches in StackWise stacking configurations. StackWise cables
are used to connect the StackWise ports for stacking.
A StackWise adapter must be installed in a StackWise port to enable stacking. StackWise adapter blanks
installed in the StackWise ports is the default setup.
For Catalyst 3650 switches in which stacking is specified, StackWise adapters are preinstalled in the
StackWise ports, and optional StackWise cables can be ordered. When stacking is not specified, but is
required, the StackWise adapter blanks must be removed and StackWise adapters installed.
Caution Use only approved cables, and connect only to similar Cisco equipment. Equipment might be damaged
if connected to nonapproved Cisco cables or equipment.
Note You cannot have a switch stack containing a mix of Catalyst 3650 and Catalyst 3850 switches.
3 CONSOLE (RJ-45 console port) 8 PS OK (output) status LED
4 MGMT (RJ-45 10/100/1000 management
port)
9 Power supply
5 Fan module
Table 1-12 RJ-45 Console Port LED
Color RJ-45 Console Port Status
1
1. The USB console has priority over the RJ-45 console.
Off RJ-45 console is disabled. USB console is active.
Green RJ-45 console is enabled. USB console is disabled.
