Cisco Catalyst 3650 Series Hardware Installation Guide

CHAPTER
4-1
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
4
Power Supply Installation
This chapter describes how to install the power supply modules. The following topics are included in
this chapter:
• Power Supply Module Overview, page 4-1
• Installation Guidelines, page 4-6
• Installing or Replacing an AC Power Supply, page 4-7
• Installing a DC Power Supply, page 4-8
• Finding the Power Supply Module Serial Number, page 4-13
Note The contents of this chapter are not applicable to the Cisco Catalyst 3650-24PDM and Catalyst
3650-48FQM switches. These switches come with fixed power supply modules and require no separate
installation.
Power Supply Module Overview
The switch operates with either one or two active power supply modules.
You can use two AC modules, two DC modules, one AC and one DC module, or one module and a blank
cover.
Note In a Network Equipment Building System (NEBS) installation, you can use two DC modules or one DC
module and a blank cover.
All the switches ship with a blank cover in the second power supply slot if switches are configured with
only one power supply.
Table 4-1 describes the supported internal power supply modules.
Table 4-1 Power Supply Module Part Numbers and Descriptions
Part Number Description
PWR-C1-1100WAC 1100-W AC power supply module
PWR-C1-715WAC 715-W AC power supply module
PWR-C1-BLANK Blank cover
