Chapter 1 Product Overview
Rear Panel
As an example, if the default power supply of 1100-W is used, the power available for connected devices
will be as follows:
Power Supply Module LEDs
The power supply modules have two status LEDs.
RPS Connector
The Cisco Redundant Power Supply (RPS) 2300 (Model PWR-RPS2300) supports the Catalyst
3650-24PDM and Catalyst 3650-48FQM switches.
Table 1-19 Available PoE with AC Power Supply
Model Power Supply Available PoE Power
24-port Cisco UPOE
switch
1100 W 820 W
48-port Cisco UPOE
switch
1100 W 660 W
Table 1-20 Switch Power Supply Requirements for Catalyst 3650-8X24UQ/PD and Catalyst
3650-12X48FD/UQ/UR/UZ Switches
24-Port Switch 48-Port Switch
Power supply combinations:
• (2) 1100 W AC
• (2) 715 W AC
• (1) 1100 W AC + (1) 715 W AC
Power supply combinations:
• (2) 1100 W AC
• (2) 715 W AC
• (1) 1100 W AC + (1) 715 W AC
Table 1-21 Switch Power Supply Module LEDs
AC Power Supply Module LEDs
AC OK Description PS OK Description
Off No AC input power. Off Output is disabled, or input is
outside operating range (AC LED
is off).
Green AC input power present. Green Power output to switch active.
Red Output has failed.
DC Power Supply Module LEDs
DC OK Description PS OK Description
Off No DC input power. Off Output is disabled, or input is
outside operating range (DC LED
is off).
Green DC input power present. Green Power output to switch active.
Red Output has failed.
