CHAPTER
2-1
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
2
Switch Installation
This chapter describes how to install and connect a Catalyst 3650 switch. It also includes planning and
cabling considerations for stacking switches.
Read the topics and perform the procedures in this order:
1. Preparing for Installation, page 2-1
2. Planning a Switch Data Stack, page 2-5
3. Installing the Switch, page 2-9
4. Installing the StackWise Ports, page 2-15
5. Installing and Removing an SFP and SFP+ Module, page 2-17
6. Connecting a Device to an Ethernet Port, page 2-19
7. Where To Go Next, page 2-21
For initial switch setup, how to assign the switch IP address, and for powering information, see the
switch getting started guide on Cisco.com.
Preparing for Installation
Ensure that the following sections are read and understood carefully before the switch is installed.
Safety Warnings
This section includes the basic installation caution and warning statements. Translations of the warning
statements appear in the Regulatory Compliance and Safety Information for the Catalyst 3650 Switch at
http://www.cisco.com/c/en/us/td/docs/switches/lan/catalyst3650/hardware/regulatory/compliance/cat3
650_rcsi.html. Read this section before you start the installation procedure.
Warning
Before working on equipment that is connected to power lines, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat up when connected to power and ground and can
cause serious burns or weld the metal object to the terminals.
Statement 43
Warning
Do not stack the chassis on any other equipment. If the chassis falls, it can cause severe bodily injury
and equipment damage.
Statement 48
