Catalyst 3750-X and 3560-X Switch Software Configuration Guide

OL-21521-01

Chapter 48 Configuring IP Multicast Routing

Monitoring and Maintaining IP Multicast Routing

Monitoring IP Multicast Routing

You can use the privileged EXEC commands in Table 48-7 to monitor IP multicast routers, packets, and

paths:

Ta ble 48-7 Commands for Monitoring IP Multicast Routing

Command Purpose

mrinfo [ho

stname | address] [source-address |

interface]

Query a multicast router or multilayer switch about which neighboring

multicast devices are peering with it.

mstat sour

ce [destination] [group] Display IP multicast packet rate and loss information.

mtrace so

urce [destination] [group] Trace the path from a source to a destination branch for a multicast

distribution tree for a given group.
