37-40

Catalyst 3750-X and 3560-X Switch Software Configuration Guide

OL-21521-01

Chapter 37 Configuring Network Security with ACLs

Using VLAN Maps with Router ACLs

Figure 37-7 Applying ACLs on Bridged Packets

ACLs and Routed Packets

Figure 37-8 shows how ACLs are applied on routed packets. The ACLs are applied in this order:

1. VLAN map for input VLAN

2. Input router ACL

3. Output router ACL

4. VLAN map for output VLAN

Figure 37-8 Applying ACLs on Routed Packets

Frame

Fallback bridge

VLAN 10

Host A

(VLAN 10)

Packet

101358

VLAN 20

Host B

(VLAN 20)

VLAN 10

map

VLAN 20

map

Frame

Routing function

VLAN 10

Host A

(VLAN 10)

Packet

101359

VLAN 20

Host B

(VLAN 20)

VLAN 10

map

Input

router

ACL

Output

router

ACL

VLAN 20

map
