26-20
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 26 Configuring IGMP Snooping and MVR
Configuring MVR
• MVR can coexist with IGMP snooping on a switch.
• MVR data received on an MVR receiver port is not forwarded to MVR source ports.
• MVR does not support IGMPv3 messages.
Configuring MVR Global Parameters
You do not need to set the optional MVR parameters if you choose to use the default settings. If you do
want to change the default parameters (except for the MVR VLAN), you must first enable MVR.
Note For complete syntax and usage information for the commands used in this section, see the command
reference for this release.
Beginning in privileged EXEC mode, follow these steps to configure MVR parameters:
To return the switch to its default settings, use the no mvr [mode | gr
oup ip-address | querytime | vlan]
global configuration commands.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
mvr Enable MVR on the switch.
Step 3
mvr group ip-address [count] Configure an IP multicast address on the switch or use the count parameter to
configure a contiguous series of MVR group addresses (the range for count is
1 to 256; the default is 1). Any multicast data sent to this address is sent to all
source ports on the switch and all receiver ports that have elected to receive
data on that multicast address. Each multicast address would correspond to
one television channel.
Step 4
mvr querytime value (Optional) Define the maximum time to wait for IGMP report memberships
on a receiver port before removing the port from multicast group membership.
The value is in units of tenths of a second. The range is 1 to 100, and the
default is 5 tenths or one-half second.
Step 5
mvr vlan vlan-id (Optional) Specify the VLAN in which multicast data is received; all source
ports must belong to this VLAN. The VLAN range is 1 to 1001 and 1006 to
4094. The default is VLAN 1.
Step 6
mvr mode {dynamic | compatible} (Optional) Specify the MVR mode of operation:
• dynamic—Allows dynamic MVR membership on source ports.
• compatible—Is compatible with Catalyst 3500 XL and Catalyst 2900 XL
switches and does not support IGMP dynamic joins on source ports.
The default is compat
ible mode.
Step 7
end Return to privileged EXEC mode.
Step 8
show mvr or show mvr members Verify the configuration.
Step 9
copy running-config
startup-config
(Optional) Save your entries in the configuration file.
