Page #191 background image
CHAPTER 13
Monitoring the Interface Card in the Cisco cBR
Chassis
Monitoring the Interface Line Cards in the Cisco cBR Chassis using LEDs, on page 183
Monitoring the Digital Physical Interface Cards in the Cisco cBR Chassis using LEDs, on page 184
Monitoring the Interface Line Cards in the Cisco cBR Chassis
using LEDs
Table 41: Verifying the LEDs on the Interface Line Cards
DescriptionStatusLED
The line card has not initialized correctly.OffSTATUS
The line card has initialized, but HA fault is
detected.
Possible hardware fault.
Yellow
The line card is operational.Green
The Interface line card is not a Protect card.
OffPROTECT
The Interface line card is configured as a Protect
card.
Blue
The Protect card is operational and traffic is
flowing.
Green
The Interface line card is operational and does
not require replacement.
OffREPLACE
The Interface line card requires replacement.White
Cisco Converged Broadband Routers Hardware Installation Guide
183
