Cisco cBR Series Hardware Installation Guide

Monitoring the Supervisor 160G in the Cisco cBR Chassis Using
LEDs
Table 37: Verifying the LEDs on the Supervisor Card
DescriptionStatusLED
Supervisor Card is not powered up.OffPWR STAT
Supervisor Card is powered up.Green
Supervisor Card has a power fault
- at least one voltage rail exceeded
its voltage threshold limit.
Yellow
Supervisor Card has a power fault
- less than the minimum number of
fan modules with no fault condition
detected at power-on.
Blinking green at a 2 seconds rate
Supervisor Card has a power fault
- less than the minimum number of
power modules with no fault
condition detected at power-on.
Blinking yellow at a 2 seconds rate
Supervisor Card has a power fault
- the Supervisor PIC is not detected
at power-on.
Blinking between green and yellow
at a 2 seconds rate
Supervisor Card has a power fault
- either the Supervisor PIC,
SUP-DC, or SUP-MB did not
respond with a PGOOD signal
within 3 seconds after power-on.
Blinking yellow at a 1/4 second rate
Software on the other Supervisor
Card has turned off power on this
Supervisor Card.
Blinking green at a 1/4 second rate
Secure Boot authentication has
failed and Supervisor Card is
powered down.
Blinking between green and yellow
at a 1/4 seconds rate
RP has not booted.
OffRP STAT
Software is loading.Blinking green
RP is operational.Green
RP has detected a fault.Yellow
Cisco Converged Broadband Routers Hardware Installation Guide
176
Monitoring the Supervisor in the Cisco cBR Chassis
Monitoring the Supervisor 160G in the Cisco cBR Chassis Using LEDs
