Step 26 Copy the configuration into bootflash for backup.
copy running-config bootflash:sup250.cfg
copy running-config stby-bootflash:sup250.cfg
Step 27 Check the WAN port connection by ping the peer device.
Step 28 Check the system health and service with the following commands:
show version
show platform
show platform diag
show environment
show cable modem summary total
show processes cpu sorted
show logging
Upgrade Supervisor 160G to Supervisor 250G 100GE Mode
Backup the Configuration and IOS Code
Step 1 Insert the Cisco certified eUSB disk into the USB0 on the active SUP160 board.
Step 2 Edit the configuration follow the steps below:
Please note that on SUP250, all 10G and 100G interfaces are visible regardless of whether the related QSFP module is
inserted or not. The backhaul interface numbering scheme on SUP250 is different from SUP160, shown as below:
10GE interface100GE interface
Te4/1/2 ~ Te4/1/9Hu4/1/0 ~ Hu4/1/1SUP4
Te5/1/2 ~ Te5/1/9Hu5/1/0 ~ Hu5/1/1SUP5
Therefore, we recommend the user to copy the SUP160 configuration out to the server and edit the SUP160 configuration
manually before copy back to the SUP250.
a) Replace the card type sup-pic-8x10g with sup-pic-2x100g-8x10g on both card 4/1 and 5/1.
card 0/0 cBR-CCAP-LC-40G
card 1/0 cBR-CCAP-LC-40G
card 2/0 cBR-CCAP-LC-40G
card 3/0 cBR-CCAP-LC-40G
card 4/1 sup-pic-2x100g-8x10g
card 5/1 sup-pic-2x100g-8x10g
card 6/0 cBR-CCAP-LC-40G
card 7/0 cBR-CCAP-LC-40G
card 8/0 cBR-CCAP-LC-40G
card 9/0 cBR-CCAP-LC-40G
b) Remove all TenGig interface configurations from file, for example:
interface TenGigabitEthernet4/1/0,
interface TenGigabitEthernet4/1/1,
interface TenGigabitEthernet4/1/2,
interface TenGigabitEthernet4/1/3,
interface TenGigabitEthernet4/1/4,
interface TenGigabitEthernet4/1/5,
Cisco Converged Broadband Routers Hardware Installation Guide
135
Installing the Supervisor in the Cisco cBR Chassis
Upgrade Supervisor 160G to Supervisor 250G 100GE Mode
