46
SPECIAL FEATURES : TIGHTENING TORQUES (m.daN)
Crankshaft
Engines 8HY-8HV
Bearing cap fixing screw
Tightening 3 ± 0.3
Angular tightening 140°±1°.4'
Crankshaft pullet hub
Tightening 3 ± 0.3
Angular tightening 180° ± 5°
Cylinder block
Oil sump 1 ± 0.1
Timing belt tensioner roller 4 ± 0.4
Timing belt guide roller
2.5 ± 0.2
Timing belt guide roller support
Cylinder head
Camshaft bearing cap cover
1 ± 0.1
Inlet manifold
Exhaust manifold 2.5 ± 0.2
Cylinder head cover Bolts (M6) to 1 ± 0.2
Camshaft pinion 4.3 ± 0.4
Fuel high pressure pump pinion 5 ± 0.5
ENGINE
