87
SPECIAL
FEA
TURES
:
POWER UNIT
SUSPENSION
Engines :
8HX
- 8HW
T
ightening torques
(m.daN)
RH engine
support.
(1) :
4,5
±
0,4
(2) :
3
±
0,3
T
orque
reaction rod.
(3) :
6
±
0.6
(4) :
6
±
0.6
LH engine
support.
(5) :
5.4
±
0.5
(6) :
6
±
0.6
(7) :
5.5
±
0.5
ENGINE
B1BP2LJP
88
90
