ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
170
Group: Process Control
Subgroup: Load Control
Setpoint group Process Control Related FW 2.0.0
Range [units] Baseload / Loadsharing [-]
Default value Baseload Alternative config NO
Step [-]
Comm object 8774 Related applications MCB, MGCB, BTB
Description
Load control mode in parallel to mains operation of the whole group of gen-sets.
Baseload
The total power of the group is controlled to constant level given by the setpoint
#System BaseLoad (page 171). Each loaded gen-set takes equal part (relative to their
nominal power) from this requested value. The load is regulated locally in each
controller by Load control regulation loop, load-sharing is not active. The setpoint
#System BaseLoad (page 171) is also used for determining which gen-sets have to run
or not.
Loadsharing
Gen-sets load is controlled by IM210 controller to share the total load (given by the
setpoint #System BaseLoad (page 171)) with other loaded gen-sets in such a way, that
all loaded gen-sets will be loaded at the same level (relative to gen-set nominal power).
Load-sharing regulation loop is active.
Note: The Loadsharing mode shall be used in case a IM210 controller is present in the system. In
systems without IM210 the setpoint must be in the Baseload position.
Note: The power factor (PF) is regulated to constant level given by the setpoint #System PF Control PTM
(page 170) in parallel to mains operation and does not depend on active load control mode.
#System Load Control PTM
6 back to List of setpoints
Setpoint group Process Control Related FW 2.0.0
Range [units] Base PF / Var Sharing [-]
Default value Base PF Alternative config NO
Step [-]
Comm object 8779 Related applications MCB, MGCB, BTB
Description
Power factor control mode in parallel to mains operation of the whole group of gen-sets.
Base PF
Gensets PF is controlled by their PF control loops to provide constant power factor
adjusted by setpoint #System Power Factor (page 171). InteliMains doesn't play active
role in PF control in parallel to mains operation.
Var Sharing Gensets PF is controlled by InteliMains through the VAr sharing line.
#System PF Control PTM
6 back to List of setpoints
