InteliMains 210 Global Guide
75
5.4.18 Alternate configuration 127
5.4.19 USB host 128
6 back to Controller setup
5.4.1 Operating Modes
Selecting the operating mode is done through Left and Right buttons on the front panel or by changing the
Controller mode (page 178) setpoint (from the front panel or remotely).
Note: If this setpoint is configured as password-protected, the correct password must be entered prior to
attempting to change the mode.
Note: The mode cannot be changed if Access Lock input is active.
The following binary inputs can be used to force one respective operating mode independent of the mode
setpoint selection:
Remote OFF (page 432)
Remote MAN (page 432)
Remote AUTO (page 431)
If the respective input is active the controller will change the mode to the respective position according to the
active input. If multiple inputs are active, the mode will be changed according to priorities of the inputs. The
priorities match the order in the list above. If all inputs are deactivated, the mode will return to the original
position given by the setpoint.
OFF
All regulations are switched off. Switching to OFF mode causes opening of BTB regardless of the settings.
MAN
It is possible to close/open BTB manually under supervision of InteliMains controller (automatic synchronization
is started if there are voltages on both sides).
AUTO
Controller closes automatically BTB if:
bus voltages are within the limits
there is voltage on both, one or none of the buses and closing to dead bus is enabled
5.4.2 Connecting to load
Connecting to dead bus
BTB
Behavior of connecting to dead bus is adjusted by setpoint Dead Bus Closing (page 174).
Note: There is also a protection of "Bus power loss sensing". The "Bus Measurement Error" is detected when
the BTB is closed and the bus parameters are out of limit for 20s. Bus Measurement Error can be disabled by
setpoint.
