8 Steering
8.1 Structure of Steering
8.1.1 Structure
• Full hydraulic system is applied for power steering. This power steering is provided with an orbit roll type
hydraulic steering unit in the steering system.
• This system reduces the steering effort of operator by guiding the forced feed oil from the pump to the unit and
sending to the double-acting hydraulic cylinder while controlling.
Steeringwheel
Returnhose
Pressurehose
HoseL
HoseR
Steeringshaft
Steeringunit
(orbitroll)
HoseL HoseR
HoseL
HoseR
Adaptor
GZ3W27-001
