Cub Cadet 7530 Maintenance Manual

Maintenance Standard 1
1
1 Maintenance Standard
1.1 List of Maintenance Standard
(Unit : mm {in})
Item Standard Value Limit Value Remarks
Clutch
Free play for clutch pedal
20 to 30
{0.79 to 1.18}
Rivet countersink amount
1.3 to 1.9
{0.051 to 0.075}
0.20
{0.008}
Backlash
0.05 to 0.15
{0.002 to 0.006}
0.30
{0.012}
Clearance bet. release shaft and bush
0.04 to 0.12
{0.0016 to 0.005}
0.30
{0.012}
Clearance bet. shaft and bush
0.04 to 0.12
{0.0016 to 0.005}
0.50
{0.020}
HST
Free play for speed control lever
25 to 30
{0.98 to 1.18}
Transmission
Rod length of main gearing
Speed (1 to 2) 351 {13.8}
Speed (3 to 4) 385 {5.2}
Shuttle rod length 412 {6.2}
PTO drive shaft Endplay for bearing and case
0.05 to 0.20
{0.002 to 0.008}
Rear PTO shaft Endplay for bearing and liner B
0.05 to 0.20
{0.002 to 0.008}
Sub shaft Endplay for bearing and case
0.05 to 0.20
{0.002 to 0.008}
4WD Shift Endplay for bearing and case
0.05 to 0.20
{0.002 to 0.008}
Shaft Endplay for bearing and case
0.05 to 0.20
{0.002 to 0.008}
Main shift Endplay for bearing and case
0.05 to 0.20
{0.002 to 0.008}
