1 Maintenance Standard

1.3 List of Torque

Unit : (N•m {kgf•cm, lbf•ft})

Tightened Parts Torque

Double nut for engine control lever 0.78 to 0.98 {8 to 10, 0.58 to 0.72}

Mounting bolt for front axle bracket

(Engine left/right)

93.2 to 108 {950 to 1100, 68.7 to 79.6}

(Engine forepart)

118 to 132 {1200 to 1350, 86.8 to 97.6}

Drain plug for front axle case 20.6 to 29.4 {210 to 300, 15.2 to 21.7}

Air plug for front axle 11.8 to 16.7 {120 to 170, 8.68 to 12.3}

Drain plug front axle 11.8 to 16.7 {120 to 170, 8.68 to 12.3}

Drain plug for front axle center case 39.2 to 49.0 {400 to 500, 28.9 to 36.2}

Mounting bolt for kingpin case 58.8 to 68.6 {600 to 700, 43.4 to 50.6}

Mounting bolt for front axle center case 49 to 58.8 {500 to 600, 36.2 to 43.4}

Locking bolt for tie rod

Temp. tightening : 147 to 167

{1500 to 1700, 108 to 123}

Tightening : 9.8 {100, 7.23}

Locking nut for tie rod end

Temp. tightening : 44.1 to 53.9

{450 to 550, 32.5 to 39.8}

Tightening : 9.8 {100, 7.23}

Lock nut for tie rod end (Toe-in adjustment) 147 to 167 {1500 to 1700, 108 to 123}

Power steering hose 29.4 to 39.2 {300 to 400, 21.7 to 28.9}

Mounting joint for power steering 24.5 to 29.4 {250 to 300, 18.1 to 21.7}

Steering unit joint 24.5 to 29.4 {250 to 300, 18.1 to 21.7}
