6 Specification
24
6Specification
Model 30hp GEAR 32hp HST
Engine
Model K3M - DT
Type Water Cooling 4-Cycle Diesel
Type of Injection Direct Injection Type
Rated Output (Gross Value) KW {HP} 22.4 {30} 23.9 {32}
Rated Output (Net Value) KW {HP} -
PTO Output Gear Specification KW {HP} 19.1 {26} -
PTO Output HST Specification KW {HP} - 19.1 {26}
Rated Engine Speed rpm 2500
Number of Cylinder 3
Gross Displacement cc {in
3
} 1496 {91.3}
Boa × Stroke mm {in} 84 × 90{3.31 × 3.54 }
Oil Filter Cartridge Type
Air Filter Double Dry Type
Fuel Tank Capacity L {USgal} 27 {7.1}
Reserve Tank Standard
Generation Capacity A 40
Body Dimension
With AG Tire With AG Tire
Full Length 3 - PH mm {in} 3070 {120.9}
Full Width (Min. Tread) mm {in} 1270 {50} 1330 {52.4}
Full Height (2-column Frame) mm {in} 2105 {82.9} 2130 {83.9}
Wheel Base mm {in} 1710 {67.3}
Min. Under Clearance mm {in} 337 {13.3} 364 {14.3}
Wheel Base
Front Wheel mm {in} 1070 {42.1}
Rear Wheel mm {in} 1080 {42.5}
Turning Radius (with Brake) m {in} 2.4 {94.5}
Vehicle Gross Weight kg {lbs} 1050 {2315} 1110 {2447}
Shared Load
Front Wheel kg {lbs} 460 {1014} -
Rear Wheel kg {lbs} 535 {1180} -
Power Transmission Drive
Main Change Gear Constant-Mesh (Main) -
Number of Gearing Stage Drive: 8, Rev-drive: 8 -
Shuttle (Drive & Reverse Drive) Synchro -
HST
No. of Gearing Stage - 3 Stages
Driving Control - Standard
Rated of March km/h 1.4 to 18.1 (9.5 to 24) 0 to 20.6( 355/80D20)
Creep Rate (Gear) - -
Final Drive Spur
Brake
Brake Wet Disc
Parking Brake Ratchet
Clutch (Disc Diameter) mm {in} Dry Type Single Plate (ø 215{8.464})
Four-Wheel Drive Standard
Gear Ratio (Front Wheel/Rear Wheel) 1.527 1.532
