D-Link DSL-3900 User Manual

10D-Link DSL-3900 User Manual
Section 2 - Installation
Manual Setup
1
Position your DSL-3900 near your PC and a telephone wall jack which provides DSL service. Keep the modem router in
an open area for better wireless coverage.
2
Plug one end of the supplied DSL phone cable into the DSL port on the back of the modem router, and the other end
into the telephone wall jack.
Note: If a DSL microsplitter/microlter is included in the package contents, install it in line with your telephone wall
jack.
PC
DSL-3900
Phone
PC
DSL-3900
Phone

D-Link DSL-3900 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1753 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2
Processor cores	2

Weight and Dimensions

Depth	45.5 mm
Width	258.8 mm
Height	184.1 mm
