D-Link DSL-3900 User Manual

57D-Link DSL-3900 User Manual
Section 4 - Conguration
IP/MAC/Web Filtering
IP Filter
The IP Filters page manages LAN users' access to the Internet. It is possible
to permit access to the Internet for specied IP addresses within your LAN or
to restrict access for specied IP addresses. You can also dene lters for port
access. To access this page, click IP/MAC/Web Filtering from the Features
menu on the bar on the top of the page.
You may choose from the following options: Disable IP Filters, Only allow
computers with IP addresses listed below access to the network, or Only
deny computers with IP addresses listed below access to the network.
The currently dened IP lters are displayed in the table. You may dene up to
16 IP ltering rules. If you wish to remove a rule, click on its trash can icon (
)
in the Delete column. If you wish to edit a rule, click on its pencil icon (
) in the
Edit column. If you wish to create a new rule, click the Add Rule button.
The following page contains a detailed description of rule creation.

D-Link DSL-3900 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1753 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2
Processor cores	2

Weight and Dimensions

Depth	45.5 mm
Width	258.8 mm
Height	184.1 mm
