D-Link DSL-3900 User Manual

32D-Link DSL-3900 User Manual
Section 4 - Conguration
WAN Settings
Dynamic IP (DHCP)
Select Dynamic IP Address (DHCP) to obtain an IP address automatically
from your ISP. Select this option if your ISP does not provide you with a specic
IP address.
WAN Settings
Connection: Select Dynamic IP Address (DHCP).
Connection Type: Select Bridged IP LLC, Bridged IP VC-MUX, Routed IP LLC, or Routed
IP VC-Mux.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
NAT Enable Enable or disable NAT.
Enable PPPoE
Passthrough
Enable or disable PPPoE Passthrough.
Click Save when you are done.
From this page you can congure your WAN settings. To access this page, click Internet from the Settings menu on the bar on
the top of the page. Then click Advanced Settings... on the right side, then scroll down to WAN Settings

D-Link DSL-3900 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1753 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2
Processor cores	2

Weight and Dimensions

Depth	45.5 mm
Width	258.8 mm
Height	184.1 mm
