D-Link DSL-3900 User Manual

22D-Link DSL-3900 User Manual
Section 4 - Conguration
IPv4
DSL Type: Displays the current DSL type, either ADSL or VDSL.
Cable Status: Displays the current cable connection status.
Link Rate: Displays the currently negotiated connection speed.
Connection Type: Displays the network protocol used to obtain an IP address.
Network Status: Displays the current network connection status.
Connection
Uptime:
Displays the amount of time the connection has been connected.
MAC Address: Displays the MAC address of this interface.
IP Address: Displays the current WAN IPv4 address.
Subnet Mask: Displays the current subnet mask.
Default Gateway: Displays the current IPv4 default gateway.
Primary DNS
Server:
Displays the current primary DNS server.
Secondary DNS
Server:
Displays the current secondary DNS server.
IPv4
Click the IPv4 button to see the IPv4 information for the DSL interface. If you
have congured your ADSL/VDSL connection to use PPPoE with On-Demand
or Manual settings, you can connect to or disconnect from the Internet by
pressing the Connect or Disconnect buttons.

D-Link DSL-3900 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1753 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2
Processor cores	2

Weight and Dimensions

Depth	45.5 mm
Width	258.8 mm
Height	184.1 mm
