102
DCS-2100 User’s Manual
D-Link Systems, Inc.
Using IP Surveillance Software
The video channel selection area provides the IP addresses
and location information of the connected video channels for
the user’s reference. You can select a video channel in this area
and create a schedule for it.
The Primary schedule consists of the day time-line, week time-
line, begin time selector, end time selector, and event mode
settings.
The Secondary schedule consists of event mode settings.
The operation buttons allow the user to manipulate the edited
schedule of the selected video channel. The scheduler can be
closed from here.
Video Channel
Selection Area:
Primary Schedule:
Secondary
Schedule:
Operation Buttons:
The Functionalities of Configuration Components
The four main parts of the scheduler have been briefly described above. The four parts
will be described in detail in the following section.
In this area you will select the video channel that you want to set a schedule for. Each
video channel will display a name, IP address, and location. Please note that when you
switch between video channels in this area, the changes in the schedule of the previous
video channel will be saved automatically.
Video Channel Selection Area
