106
DCS-2100 User’s Manual
D-Link Systems, Inc.
Using IP Surveillance Software
This button allows you to load pre-edited schedules from the
scheduling directory for the selected video channel. Note that
you should save the schedule you are currently working on
before loading a new one. Otherwise, the current changes will
be lost.
This button will clear all changes in the current schedule of the
selected video channel.
This button is used for saving changes to the current schedule.
Schedule modes
If you select Continuous mode in the schedule mode selector, it will record continuously
during the schedule that is set up by the user.
Secondary Schedule
Secondary schedule is for recording outside of the primary schedule. The secondary
schedule provides options to record without a specified date or time.
Schedule in Continuous mode
Operation Buttons
There are six operation buttons that allow you to handle the schedule schemes: “Load…”,
“Undo”, “Clear”, “Save”, “Save as…” and “Close.” These operation buttons are shown in
the figure below.
Load...:
There are three modes in the secondary schedule: Disable, Event mode, and Continuous
mode. If event mode is selected in the secondary schedule, the camera will record
whenever an event is triggered. If continuous mode is selected, the camera will begin
recording continuously after scheduling settings are saved. These two modes are the
same as the primary schedule. Please refer to the previous section for more detail.
Clear:
Save:
