ESIE09-08B Troubleshooting by Indication on the Remote Controller
Troubleshooting 185
3.44 “L8 ” Indoor Unit: Inverter Current Abnormal
Remote Control
Display
L8
Subcode 10
Applicable
Models
All indoor units
Method of
Malfunction
Detection
Malfunction is detected by current flowing in the power transistor.
Malfunction
Decision
Conditions
When overload in the compressor is detected.
Supposed
Causes
Compressor overload
Compressor coil disconnected
Defect of indoor unit PC board [A4P (1
ø) or A5P (3ø)]
Current protection (thermal)
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect
connector, or parts damage may be occured.
Output current check
Inverter
output voltage
check Inverter output
voltage is not balanced
(Normal if within 5V). Must
be measured when
frequency
is stable
Compressor overload
Inspection of the compressor and
refrigerant system is required
Compressor inspection
Inspect according to the diagnosis
procedure for odd noises, vibration
and operating status of the
compressor
NO
Replace the inverter PC board assy
[A4P (ø) or A5P (ø)]
YES
NO
Reset en Restart
NO
Replace the compressor
NO
YES
Compressor
inspection The
compressor's coil is
disconnected.
YE S
YES
Disconnect the connection
between the compressor and
inverter. Make the power
transistor check mode setting
ON by service mode.
After
turning on again,
"L8 - 10" blinks again.
The
secondary current
of the inverter is higher
than 13.1A, 260 sec for
each phase.
To Next Page
