ESIE09-08B 3-Way Valve
Appendix 261
8. 3-Way Valve
8.1 Build-Up of 3-Way Valve
Total assembly
Legend
Actuator
asse
mbly
No. Name
1 Sleeve
2 Valve motor cover
3 Screw
4 Turn knob
