Switch Box Layout - Indoor Unit EKHBRD ESIE09-08B
28 Refrigerant Circuit
1. Switch Box Layout - Indoor Unit EKHBRD
EKHBRD 011/014/016 AAV1
EKHBRD 011/014/016 AAY1
A7P
X3M
Fieldwiring
to X3M, A8P
Fieldwiring
to X2M, A7P
Fieldwiring
to X1M
X1M
X2M
C1
X2Y
X1Y
X3Y
A5P
A4P
A6P
A8P
A3P
A1P
K1A
