PCB Layout for EKHBRD 011/014/016 AA/AB/AC/AD V1/Y1 ESIE09-08B
38 Refrigerant Circuit
2.4 Filter PCB - A6P
Filter PCB - single phase
LBblue
LAred
earthgreen cable + white connector
Connector of LF - NF white
NB blue
LB red
LF NF 6,3A 250V
Fuse F1U
