Daikin Altherma HT Service Manual

PCB Layout for EKHBRD 011/014/016 AA/AB/AC/AD V1/Y1 ESIE09-08B
34 Refrigerant Circuit
2.2 Control - PCB - A3P
Control PCB - single phase
Control PCB - A3P
X11Ayellow
X12Ablue
X25Awhite
X13Awhite
X14Awhite
X15A
X1A b
white
X23A
green
X8A
pink
X7A
black
X5A
yellow
X4A
orange
X3A
white
X21A
black
X16A
yellow
X10A
white
X9A
white
Fuse
3,15A 250V
X11A
X21A
X10A X9A
EB0750
Fuse= 3,15A 250V
X3A X4A X5A X7A X8A X23A
X1
A
X12A
X25A
X13A
X14A

Daikin Altherma HT Specifications

General

Type	Air-to-water heat pump
Refrigerant	R-410A
Water Outlet Temperature	Up to 80°C
Operating Temperature Range	-20°C to 35°C
Power Supply	3-phase, 400V
Energy Efficiency Class (Heating)	A++
