Position Description Choices/options
24 Sensor plugs
X No sensor plugs
E
Direct mount 4xM12: 4
digital inputs
F
Direct mount 6xM12:
4
digital inputs, 2 relay
outputs
25 Motor
plug X No motor plug
26 Mains plug X No mains plug
27 Fieldbus plug
X No fieldbus plug
E M12 Ethernet
P M12 Profibus
28 Reserved X For future use
29-30 A option
AX No A option
A0 Profibus DP
AN Ethernet IP
AL ProfiNet
31-32 B option
BX No B option
BR Encoder option
BU Resolver option
BZ Safety PLC Interface
33-37 Reserved XXXXX For future use
38-39 D option
DX No D option
D0 24 V DC back-up input
Table 1.2 Type Code Description
Not all choices/options are available for each FCD 302
variant. To verify if the appropriate version is available,
consult the Drive Configurator on the Internet at
Danfoss website /driveconfig.
NOTE
A
and D options for FCD 302 are integrated into the
control card. Therefore pluggable options for frequency
converters cannot be used here. Future retrofit will require
exchange of the entire control card. B options are
pluggable, using the same concept as for frequency
converters.
Introduction
VLT
®
Decentral Drive FCD 302 Operating Instructions
8 MG04F302 - VLT
®
is a registered Danfoss trademark
