Installing the camera
Steps
1. Connect the camera cable to the connector on the camera module.
2. Insert the camera module into the slot on the display panel.
3. Install the:
a. display cover
b. display assembly
c. battery
d. base cover
4. Follow the procedure in After working inside your computer.
Display (eDP) cable
Removing the display cable
Steps
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. display assembly
40
Removing and installing components
