Battery 4
WLAN 1
WWAN 1
EDP Bracket 2
USB Type C 2
Recommended tools
The procedures in this document require the following tools:
• Phillips #0 screwdriver
• Phillips #1 screwdriver
• Plastic scribe
NOTE: The #0 screw driver is for screws 0-1 and the #1 screw driver is for screws 2-4
Tarjeta Micro Secure Digital (micro-SD)
Removing the Micro Secure Digital (SD) Card
CAUTION
: Removing the Micro SIM card when the computer in on may cause data loss or damage the card. Ensure that the
computer is turned o.
NOTE: Micro SIM card tray is available only for systems that are shipped with WWAN card.
1 Follow the procedure in Before working inside your computer.
2 Press in on the Micro SD card to release it from the computer.
3 Slide the Micro SD card out of the computer.
Installing the Micro Secure Digital (SD) Card
1 Slide the Micro SD into the slot until it clicks into place.
2 Follow the procedures in After working inside your computer.
Subscriber Identity Module (SIM) Card
Removing the micro SIM card or the micro SIM card tray
CAUTION
: Removing the micro SIM card when the computer is on may cause data loss or damage the card.
NOTE: Micro SIM card tray is available only for systems that are shipped with WWAN card.
1 Insert a paperclip or a micro SIM card removal tool into the pinhole on the micro SIM card tray.
2 Use a scribe to pull the micro SIM card tray.
3 If a micro SIM card is available, remove the micro SIM card from the micro SIM card tray.
10
Extracción e instalación de componentes
