4 Install the:
a battery
b base cover
c SIM card
d MicroSD card
NOTE: To install both cards if equipped.
5 Follow the procedure in After working inside your computer.
NOTE: The IMEI number can also be found on the WWAN card.
Placa de alimentación
Removing the power board
1 Follow the procedure in Before working inside your computer.
2 Remove:
a MicroSD card
b SIM card tray
NOTE: To remove both cards if equipped and no need to remove the blank ller.
c base cover
d battery
3 To remove the power board:
a Lift the coin cell battery axed to the computer [1].
b Disconnect the power cable from the power board [2].
c Remove the M2.0x3.0 screws to release the power board [3].
d Lift the power board from the computer [4].
Extracción e instalación de componentes
17
