e SSD card

f battery

g base cover

h SIM card

i MicroSD card

NOTE: To install both cards if equipped.

7 Follow the procedure in After working inside your computer.

Reposamanos

Replacing palm rest

1 Follow the procedure in Before working inside your computer.

2 Remove the:

a base cover

b battery

c SSD module

d WLAN card

e WWAN card

f heat sink assembly

g speaker

h display assembly

i system board

j keyboard

The component you are left with is the palmrest.

3 Replace the palmrest.

4 Install the:

Extracción e instalación de componentes

Questions and Answers:

Need help?

Do you have a question about the Dell Latitude 7389 2-in-1 and is the answer not in the manual?

General

Graphics	Intel HD Graphics 620
Operating System	Windows 10 Pro
Display	13.3-inch FHD (1920 x 1080) Touchscreen
Processor	Intel Core i5-7300U
RAM	Up to 16GB DDR4
Battery	60 Whr battery
Ports	HDMI, microSD card reader, headphone/microphone combo jack
Wireless	Bluetooth 4.2
