Dell Latitude 7389 2-in-1 User Manual

Installing battery
1 Insert the battery into the slot on the computer.
2 Connect the battery cable to the connector on the system board.
3 Replace the M 2 x 4L screws to secure the battery to the computer.
4 Install the:
a base cover
b SIM card
c Micro SD card
NOTE
: To install both cards if equipped .
5 Follow the procedure in After working inside your computer.
PCIe Solid State Drive (SSD)
Removing the NVMe SSD card
1 Follow the procedure in Before working inside your computer.
2 Remove:
a MicroSD card
b SIM card
NOTE
: To remove both cards if equipped and no need to remove the blank ller.
c base cover
d battery
NOTE
: Disconnect the battery cable from the system board and remove the battery.
Extracción e instalación de componentes 13
