Dell Latitude 7389 2-in-1 User Manual

e SSD card
f battery
g base cover
h MicroSD card
i SIM card
NOTE: To install both cards if equipped.
3 Follow the procedure in After working inside your computer.
Teclado
Removing keyboard assembly
NOTE: The keyboard and the keyboard tray together are called the keyboard assembly.
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Micro SD
b SIM card tray
NOTE: To remove both cards if equipped and no need to remove the blank ller.
c base cover
d battery
e SSD card
f WLAN card
g WWAN card
h Heatsink assembly
i system board
3 To Disconnect the cables and thermal pad:
a LED board cable [1]
b SSD thermal pad [2]
c Touchpad and USH board cable [3]
d keyboard and keyboard backlight cable [4]
Extracción e instalación de componentes
33
