Dell Latitude 7389 2-in-1 User Manual

3 To remove the NVMe SSD card:
a Loosen the M2.0 x 3.0 screws that secure SSD thermal bracket [1].
b Lift the thermal bracket from the SSD card [2,3].
c Slide and remove the SSD card from the slot [4].
Installing the NVMe SSD
1 Insert the NVMe SSD card into the connector.
2 Install the thermal bracket over the SSD card.
3 Tighten the M2.0 x 3.0 screws to secure the SSD thermal bracket.
4 Install the:
a battery
b base cover
c MicroSD card
d SIM card
NOTE
: To install both cards if equipped .
5 Follow the procedure in After working inside your computer.
Tarjeta WLAN
Removing the WLAN card
1 Follow the procedure in Before working inside your computer.
2 Remove:
a MicroSD card
b SIM card
14
Extracción e instalación de componentes
