PowerEdge R510 Technical Guide 11
3 System Overview
PowerEdge R510 provides a value 2S 2U server, with maximized storage capacity, high performance,
simplified management, and an affordable price.
Table 2. Product Features Summary
PowerEdge R510–4 drives
PowerEdge R510–8 drives
Chipset
Intel® 5500 chipset (Intel 5500 chipset 24 + ICH10R)
CPU
Intel® Xeon® 5500 series processors (Intel 5500 Chipset EP)
DIMM
4+4 DDR3
Unbuffered w/ECC or Registered w/ECC
1333/1066/800MHz
Memory
Modules
1GB UDIMM/RDIMM
2GB UDIMM/RDIMM
4GB RDIMM
1GB UDIMM/RDIMM
2GB UDIMM/RDIMM
4GB RDIMM
8GB RDIMM
16GB RDIMM (Available December 2009)
TPM
TPM
TCM/NO TPM
Expansion
Slots
Riser 1: 3 x PCIe +1 x Storage
or
Riser 2: 1x PCIe + 1x Storage (for GPGPU solution only)
LOM
Two GbE (5716 dual port) w/o TOE
Management
Dell OpenManage™
Baseboard Management Controller (BMC), IPMI2.0 compliant
Optional: iDRAC6 Express, iDRAC6 Enterprise, and Vflash
USB
2 front/2 rear/2 internal 2 front/2 rear/2 internal
PSU
Non-redundant, 480W (80+ SILVER)
Auto Ranging (100V~240V)
Hot-Swap redundant 1100W
Hot-Swap redundant 750W (Available late December
2009)
Auto Ranging (100V~240V)
DC PSU
NO via OEM Solution team
Availability
Quad-pack LED diagnostic LCD diagnostic
Fan
Non-redundant
Embedded
Graphics
Matrox
®
G200eW w/ 8MB
Resolution and
Colors
1280x1024@85Hz for KVM and 1600x1200@60Hz for video out
640x480 (60/72/75/85 Hz; 8/16/32-bit color)
800x600 (60/72/75/85 Hz; 8/16/32-bit color)
1024x768 (60/72/75/85 Hz; 8/16/32-bit color)
1152x864 (75 Hz; 8/16/32-bit color)
1280x1024 (60/75/85 Hz; 8/16-bit color)
1280x1024 (60 Hz, 32-bit color) (32 bit color is only supported at 60 Hz for this resolution)
Audio
No Speaker/No Buzzer
Form Factor
2U Rack

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
