9 BIOS
9.1 Overview
A flash resides on the SPI bus for BIOS and configuration storage. A 32 Mbit device is used for this function.
This permits the BIOS to be upgraded in the field via a bootable device rather than by physically removing an
EEPROM. The System BIOS, Video BIOS, server management, and PCI configuration are housed in this
flash.
The following table clarifies what is and is not supported by the PowerEdge R510 BIOS code.
Table 13. BIOS Support
Supported
Not Supported
System BIOS
System Setup
Onboard PCI video BIOS support
SATA enabled for CDROM and HDD
PCI FW3.0 compliant
PCI-to-PCI bridge 1.0 compliant
Plug and Play BIOS 1.0a compliant
MP 1.4
SMBIOS 2.6+
USB 1.1 with legacy USB support
USB 2.0 support in BIOS during pre-boot
Dell Server Assistant 7.0 support
System Service (Utility Partition) support
iDRAC supported
Error logging via ESM and IPMI
ACPI 2.0 support (S0, OS-S4, S5 states)
I2O v1.5 ready
Selectable Boot support based on BIOS Boot Specification
v1.01
Remote BIOS Update support
Remote Configuration Interface (RCI) support
Console redirection via COM1 or COM2
PXE support based on Preboot Execution Environment
Specification v2.1
2-byte ID support
ePPID support in flash
Memory remapping support
Redundant Memory support
Memory mirroring
DDR3 RDIMM and UDIMM memory support
UEFI shell Support
iDRAC6 support
VT-d
IOAT
AC recovery staggering Power-Up
EISA
AGP
Storage clustering
BIOS Recovery
ESCD
SCSI BIOS unit testing
SCSI software such as OS driver
ESM II, ESM3, ESM4 or Hydrogen (ESM5)
DRAC III or DRAC IV
ERA/O Remote Access Card
IDE Hard drive support.
Any embedded diagnostics
SMART support
Owner Tag support
First Contact support
RCU support; resource locking feature not available in the
system with new system setup

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
