Dell PowerEdge R510 Technical Guidebook

Dell
68
Technical Guidebook’s Title
Table 33. Methodology for Data Input to Memory
How is data input to this memory?
Planar
System BIOS SPI
Flash
Loading flash memory requires a vendor-provided firmware file and loader program
which is executed by booting up the system from a floppy or OS-based executable
containing the firmware file and the loader. System loaded with arbitrary data in
firmware memory will not operate.
LOM Configuration
Data
Loading flash memory requires a vendor-provided firmware file and loader program
which is executed by booting the system from a floppy or OS-based executable
containing the firmware file and the loader. LOMs loaded with arbitrary data in
firmware memory will not operate.
iDRAC6 Controller
ROM N/A
iDRAC6 controller
RAM
iDRAC embedded system
System CPLD Loading flash memory requires a vendor-provided firmware file and loader program
which is executed by booting the system from a floppy or OS-based executable
(currently only DRMK utility support) containing the firmware file and the loader. A
system loaded with arbitrary data in CPLD memory will not operate.
System CPLD Not used
iDRAC6 Express
Internal Flash
iDRAC OS: Loading flash memory requires a vendor-provided firmware file and
loader program which is executed by booting the system from a floppy or OS-based
executable containing the firmware file and the loader. System loaded without a good
iDRAC firmware image yields a non-functional iDRAC.
Managed Services Repository: Various partitions are loaded via vendor-provided
firmware file and loader program just like iDRAC OS.
System RAM System OS
TPM ID EEPROM
(Plug in module only) Factory load only
TPM Binding
EEPROM (on China
planar only) BIOS only
iDRAC6 SDRAM
Embedded iDRAC OS for 108MB and 8MB for VGA frame buffer
iDRAC6 FRU Factory and iDRAC embedded OS
iDRAC6 Boot Block
Flash
Loading flash memory requires a vendor-provided firmware file and loader program
which is executed by booting the system from a floppy or OS-based executable or
out-of-band firmware updates across the management network. Bad content makes
the iDRAC inoperable and is unrecoverable in the customer environment. The

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
