PowerEdge R510 Technical Guide 15
4 Mechanical
4.1 Chassis Description
PowerEdge R510 chassis is a 2U rack system. The chassis is not swappable. Supported configurations are
detailed in Table 3.
Table 3. Supported Chassis Configurations
4-HDD Configuration 8-HDD Configuration
5 x cabled 3.5” HDD bay
Non-Redundant 480W PSU
Quad pack diagnostic LED
8 x hot-swap 3.5” or 2.5” HDD bay
750W redundant PSU (n+0 or n+1 option)
1100W redundant PSU (n+0 or n+1 option; will end
of life after release of 750W)
11G diagnostic LCD (identical to the PowerEdge
R710)
4.2 Dimensions and Weight
Table 4. PowerEdge R510 Weight
4-HDD Configuration 8-HDD Configuration
Form Factor
2U Rack
Dimension
(HxWxD)
3.40 x 17.19 x 24.09 (in);
86.4 x 436.6 x 610.2 (mm)
Max Weight
16 Kg/35.2 lbs
22.5 Kg /49.5 lbs
Empty Weight
13.6 Kg/29.92 lbs
13.5 Kg/29.7 lbs
Table 5. PowerEdge R510 Dimensions (4 and 8 HDD Configurations)
Note:
Measurements in this table correspond to the diagram shown in Figure 3.
Xa Xb Y Za w/ bezel Za w/o bezel Zb* Zc
482.4 mm 436.6 mm 86.4 mm 35.0 mm 21.0 mm
610.2
mm
642.0
mm
* Zb goes to the nominal rear wall external surface where the motherboard I/O connectors reside.

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
