PowerEdge R510 Technical Guide 45
Table 17. Intel 5500 Chipset P-State Projections and Turbo Mode Frequency
Proc
Number QDF#
Frequency
(GHz)
P-state
Turbo Mode
Freq (Ghz)
Stepping
1.60
Pmin+0
1.73
Pmin+1
E5502
Q1G8
1.86
Pmin+2
N/A
D-0
E5504
Q1GM
2.00
Pmin+3
N/A
D-0
L5506
Q1HG
2.13
Pmin+4
N/A
D-0
E5506 Q1GL
2.13
Pmin+4 N/A
D-0
L5520
Q1GN
2.26
Pmin+5
4C/3C: 2.4
2C/1C: 2.53
D-0
E5520 Q1GR
2.26
Pmin+5 4C/3C: 2.4
2C/1C: 2.53
D-0
L5530
Q1QX
2.40
Pmin+6
4C/3C: 2.53
2C/1C: 2.66
D-0
E5530
Q1GK
2.40
Pmin+6
4C/3C: 2.53
2C/1C: 2.66
D-0
E5540 Q1G2
2.53
Pmin+7 4C/3C: 2.66
2C/1C: 2.8
D-0
X5550
Q1GJ
2.66
Pmin+8
4C/3C: 2.93
2C/1C: 3.06
D-0
X5560
Q1GF
2.80
Pmin+9
4C/3C: 3.06
2C/1C: 3.20
D-0
X5570
Q1G9
2.93
Pmin+10
4C/3C: 3.20
2C/1C: 3.33
D-0
9.5 UEFI
The UEFI specification abstracts the firmware into protocols and drivers and defines the interface between OS
(UEFI compatible) and the UEFI pre-boot applications. The PowerEdge R510 implementation is compliant with
UEFI version 2.1. Interfaces are implemented in 64-bit processor mode.
PowerEdge R510 runs UEFI over legacy BIOS. The system BIOS executes, initializing the system and
configuring the hardware.
BIOS F2 setup has an option for selecting the desired boot mode: BIOS or UEFI.
Table 18. UEFI Summary
UEFI IS
UEFI IS NOT
• Compliant with UEFI specification 2.1
• A layer on top of the existing legacy BIOS
• Independent of processor and chipset technology.
• Running in 64-bit long mode
• Supportive of GUID Partition Table (GPT)
formatted disks
• A PIWG (DXE, PEI) implementation
• A complete rewrite of the system firmware
• Developed as a server UEFI implementation or
desktop and notebook implementations.
• Associated to AMD or Intel based platforms.
• Running in 16-bit real mode
• Supportive of legacy MBR formatted disks

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
