About Your Computer 21
WI -FI CATCHER™ LIGHT — The light operates as follows:
• Flashing green: Searching for networks
• Solid green: Strong network found
• Solid yellow: Weak network found
• Flashing amber: No signal found or error
• Off: No signal found
EXPRESSCARD SLOT — Supports one ExpressCard. The computer ships with a plastic blank installed in the slot.
You can add an ExpressCard to make WWAN connectivity available on your computer. For more information, see
"Using Cards" on page 71.
HARD DRIVE — Stores software and data. For more information, see "Hard Drive" on page 116 and "Hard drive
problems" on page 90.
Right Side View
OPTICAL DRIVE BAY — You can install devices such as a DVD drive or other optical drive in the optical drive bay.
For more information, see "Optical Drive" on page 115.
5-
IN-1 MEDIA MEMORY CARD READER — Provides a fast and convenient way to view and share digital photos,
music, and videos stored on a media memory card. The 5-in-1 media memory card reader reads the following digital
media memory cards:
• Secure Digital (SD) card/SDIO
• MultiMediaCard (MMC)
•Memory Stick
• Memory Stick PRO
• xD-Picture Card
IEEE 1394 CONNECTOR — Connects devices supporting IEEE 1394 high-speed transfer rates, such as some digital
video cameras.
1 optical drive bay 3 IEEE 1394 connector 5 video connector
2 5-in-1 media memory card
reader
4 USB connectors (2)
1 2 3 4 5
