TP70P-211LC1T/TP04P-20EXL1T Operation Manual
2-10
_ 2
2.2 Specifications and Functions
2.2.1 Functional Specifications
2.2.1.1 TP70P-211LC1T
Model
Specifications
TP70P-211LC1T
Display
Screen/Color
7” TFT LCD (65535 colors)
Resolution
800×480 pixels
Backlight type
LED backlight (It has a lifespan of 20,000 hours at a temperature of 25℃)
Display area
Width × Height = 154 × 85 (Unit: mm); 7 inches (diagonal)
USB (COM1)
USB port for programs to be uploaded
or downloaded
Transmission: Virtual communication port
Data length: 7 bits or 8 bits
Stop bit: 1 bit or 2 bits
Parity check: None/Odd/Even
Transmission rate: 9,600 bps~115,200 bps
USB port: Type B USB connector
Isolated communication
RS-485
(Extension
Communicaiton
Ports)
COM2
(supporting PLC
mode)
COM3
(supporting TP
mode)
Data length: 7 bits or 8 bits
Stop bit: 1 bit or 2 bits
Parity check: None/Odd/Even
Transmission rate: 9,600 bps~115,200 bps
Connector: Male DB-9 connector
Isolated communication
Downloading and Monitoring
Programs can be downloaded to TP via a virtual communication port of TP.
PLC Program Capacity
4 K steps
Screen Capacity
4 Mbytes

Delta TP70P-211LC1T Specifications

General

Brand	Delta
Model	TP70P-211LC1T
Category	Touch Panel
Language	English
