Delta TP70P-211LC1T User Manual

Chapter 2 Specifications and Functions
2-13
2__
2.2.3 Digital Input/Output Specifications
Model
Item
Electrical specifications for digital input terminals
24VDC (-15% ~ 20%) single common terminal
Number of inputs
TP70P-211LC1T
17
TP04P-20EXL1T
9
Connector type
Removable terminal blocks
Electrical isolation
Optocoupler
Input form
Direct current: (sinking or sourcing)
Sinking: NPN
Sourcing: PNP
Input voltage (±10%)
24 VDC, 5 mA
Input impedance
4.7 kΩ
Input terminal
TP70P-211LC1T
X0, X1
X2 ~ X7, X10 ~ X17, X20
TP04P-20EXL1T
X0, X1
X2 ~ X7, X20
Maximum input frequency
10 kHz
60 Hz
Action level
OFFON
> 16.5 VDC
ON

OFF
< 8 VDC
Response time
OFF

ON
< 20 µs
10 ms
ONOFF
< 50 µs
Model
Item
Electrical specifications for digital output terminals
Number of
outputs
TP70P-211LC1T
24
TP04P-20EXL1T
16
Connector type
Removable terminal blocks
Electrical isolation
Optocoupler
Output terminal
TP70P-211LC1T
Y0, Y1
Y2 ~ Y7, Y10 ~ Y17, Y20 ~ Y27
TP04P-20EXL1T
Y0, Y1
Y2 ~ Y7, Y20 ~ Y27
Output form
Transistor, Sinking (NPN: whose collectors are open collectors.)
Voltage
12 ~ 24VDC
Current
0.5A/output (2.5A/COM)
Response time
OFFON
Approximately 10 ms
ONOFF
Maximum output frequency
50 Hz
