TP70P-211LC1T/TP04P-20EXL1T Operation Manual
2-14
_ 2
2.2.4 Analog Input/Output Specifications
2.2.4.1 Electrical Specifications for Analog Output Terminals
Model
Item
TP70P-211LC1T / TP04P-20EXL1T
Number of channels for
analog output
4 (IO1~IO4)
Analog output range
4 ~ 20 mA, 0 ~ 20 mA
Digital conversion range
0 ~ 32000
Resolution
15 bits
Output impedance
100 Ω
Overall accuracy
When reached full scale at 25℃ (77℉), the range of error is ±0.2%.
When reached full scale between 0~55℃ (32~131
℉), the range of error is ±0.5%.
Response time
2 ms
Isolation
No isolation
Maximum output current
(Allowable load)
< 500 Ω
Protection
Short circuit protection
2.2.4.2 Electrical Specifications for Temperature / Current / Analog Input Terminals
Model
Item
TP70P-211LC1T / TP04P-20EXL1T
Number of channels
for analog input
2 (L1, L2)
Input form
Thermal resistance
Voltage / current input mode (divider type)
Applicable sensor
2-wired / 3-wired Pt100, JPt100, Pt1000,
Cu50, Cu100, Ni100, Ni1000, LG-Ni1000
-
Analog input range
-
Voltage: 0 ~ 5V, 0 ~ 10V, 0 ~ 50mV
Current: 0 ~ 20mA, 4 ~ 20mA
Overall accuracy
When reached full scale at 25℃ (77℉),
the range of error is ±0.4%.
When reached full scale between 0~55℃
(32~131
℉), the range of error is ±0.8%.
When reached full scale at 25℃ (
77℉),
the
range of error is ±0.5%.
When reached full scale between 0~55℃
(32~131
℉), the range of error is ±1%.
Response time
260 ms 130 ms
Digital conversion
range
0 ~ 32000 0 ~ 32000
Analog input
resolution
16 bits
Thermal conductivity
100 m -
Self-diagnosis
Disconnection detection -
Input impedance
2 MΩ
Voltage: 650 KΩ, divider type
Current: 249
Ω
