2.2.4.4 TP70P-211LC1T
Electrical Specifications for Analog Voltage / Current Input Terminals
Model
Item
TP70P-211LC1T
Number of inputs
4 (V0+ ~ V3+) 4 (I0 ~ I3)
Input form
Voltage (differential input)
Current (differential input)
Analog input range
±10 V
±20 mA
Digital conversion
range
±2000 ±1000
Resolution
12bits
(1 LSB = 5 mV)
11bits
(1 LSB = 20
µA)
Input impedance
1M
Ω
250
Ω
Overall accuracy
When reached full scale at 25℃ (77℉), the range of error is ±0.5%.
When reached full scale between 0~55℃ (32~131
℉), the range of error is ±1%.
Response time
3 ms / channel
Isolation
No isolation
Absolute input range
±15 V
±32 mA
2.2.4.5 TP04P-20EXL1T
Electrical Specifications for Analog Voltage / Current Output Terminals
Model
Item
TP04P-20EXL1T
Number of outputs
2 (V4 ~ V5) 2 (I4 ~ I5)
Output form
Voltage
Current
Analog output range
±10V
0 ~ 20mA
Digital conversion
range
±2000 0 ~ 4000
Resolution
12bits
(1 LSB = 5 mV)
12bits
(1 LSB = 5
µA)
Output impedance
100
Ω
Overall accuracy
When reached full scale at 25℃ (77℉), the range of error is ±0.5%.
When reached full scale between 0~55℃ (32~131℉), the range of error is ±1%.
Response time
3 ms / channel
Isolation
No isolation
Absolute output
range
±15V ±32mA
Protection
Short circuit protection
